High-Gain VHF RangeMax Antenna with GPS for BKR Series
Premium high-visibility wildland communication whip designed to deliver absolute signal resilience in rugged public safety operations.
The BK Technologies BKR0813 is a genuine original equipment manufacturer full-whip communication component engineered specifically for the 136–174MHz frequency band. Built as a high-performance quarter-wave transceiver attachment, this heavy-duty antenna integrates a high-gain VHF whip with an internal active GPS module. Utilizing a standard SMA connection configured directly for the BKR platform housing, the BK Technologies BKR0813 establishes a completely sealed mechanical interface that safeguards internal electronics against dust, dirt, and moisture ingress during remote outdoor task deployments.
This 20-Inch high-visibility whip is an indispensable resource for wildland firefighters, search and rescue squads, forestry officials, and public safety personnel tracking assets across expansive backcountry terrain. The specialized structural footprint features a striking bright orange exterior engineered from durable material to ensure maximum safety and quick visual identification in low-light or smoke-filled environments. Choosing the BK Technologies BKR0813 overcomes the severe range drop-offs common with factory-standard stubby configurations by offering an impressive signal boost of up to 2.77 dB, ensuring a secure communication path over complex ridges and valleys.
Operators must note that this wide-band VHF configuration is explicitly tuned for the 136–174MHz frequency sweep and will not function effectively on isolated UHF, 800 MHz, or aircraft frequencies. Because the physical structure extends a full 20 Inches in length, personnel should evaluate clearance requirements when securing the host transceiver to standardized chest packs or low-profile tactical belt holsters. This standalone hardware attachment operates purely as a passive transceiver antenna and internal global positioning component, meaning the handheld radio chassis, replacement batteries, and multi-unit desktop chargers are sold separately.
Key Features & Benefits
-
Wide-Band VHF Optimization: Operates flawlessly across the complete 136–174MHz spectrum to maintain continuous contact in remote zones.
-
Integrated GPS Architecture: Housing contains a built-in active global positioning asset to enable concurrent location tracking and clear voice transmission.
-
High-Visibility Shroud: Finished in an explicit bright orange safety jacket to ensure rapid asset identification during complex field maneuvers.
-
Rugged Carbon Steel Core: Built with a highly resilient spring-steel structural frame that easily flexes and recovers from thick brush or timber impacts.
-
Approved RangeMax Engineering: Delivers high-gain capabilities reaching up to 2.77 dB to significantly outperform standard aftermarket components.
Specifications
| Attribute |
Details |
| Brand |
BK Technologies |
| Model/SKU |
BKR0813 |
| Product Type |
Whip Antenna |
| Frequency Band |
VHF |
| Frequency Range |
136–174MHz |
| Connector Type |
SMA |
| Dimensions |
20 Inches |
| Color |
Orange |
Compatibility
Recommended Accessories
Frequently Asked Questions
Does this antenna model include tracking capabilities?
Yes, this specialized configuration features an internal active GPS antenna built right into the base housing to support location-tracking features.
What is the exact length of this whip antenna?
This model features a full-length quarter-wave design that measures exactly 20 Inches from the connector attachment point to the protective tip.
Can I deploy this model on a UHF radio system?
No, this component is structurally tuned for the 136–174MHz VHF frequency band and will not function on a UHF network setup.
Why is the outer protective sleeve colored bright orange?
The elastomeric outer jacket is colored high-visibility safety orange to make the equipment highly visible during intense wildland fire or emergency operations.
Is this an authorized factory replacement piece?
Yes, this is an official factory-approved BK Technologies RangeMax accessory built to meet stringent original equipment manufacturer performance tolerances.
Do I need any specialized hand tools to screw this onto my radio?
No hand tools are required because the antenna uses a standardized threaded connection base that tightens easily by turning it clockwise manually.
Warranty
1-year manufacturer’s warranty.
