Description
TE Connectivity B1443S
VHF (144-174 MHz) Mobile Antenna with Spring
High-Gain NMO Solution and 100% Replacement for Icom Antenna 2
The TE Connectivity B1443S is an industrial-grade, 5/8 wave base-loaded mobile antenna designed for high-performance communication across the 144-174 MHz VHF spectrum. Measuring 49 inches in length, this omnidirectional whip antenna features a precision-machined chrome base coil and a heavy-duty stainless steel spring. The integrated spring provides critical flexibility, allowing the antenna to deflect upon impact with low-hanging obstructions, which prevents damage to the vehicle's mounting surface and ensures long-term operational reliability for public safety, utility, and transportation fleets.
Engineered as a primary alternative for discontinued infrastructure, the TE Connectivity B1443S is 100% compatible with the legacy Icom Antenna 2 (now EOL). By utilizing the TE Connectivity B1443S, fleet managers can maintain their existing Icom mobile radio systems with a drop-in replacement that meets or exceeds the original's electrical specifications. With a 3 dBi gain and a standard NMO mount, this antenna delivers the extended range and consistent 360-degree coverage required for mission-critical VHF voice and data transmissions.
Key Features & Benefits
-
Drop-In Replacement for Icom Antenna 2: Specifically vetted to replace the End-of-Life (EOL) Icom Antenna 2 with total mechanical and electrical compatibility.
-
Integrated Shock Spring: The reinforced chrome spring absorbs physical impacts, extending the lifespan of both the antenna and the vehicle mount.
-
3 dBi High-Gain Performance: Provides superior signal propagation and increased reception sensitivity compared to standard unity-gain antennas.
-
Rugged Chrome Construction: The base loaded coil is housed in high-impact ABS and plated brass for maximum corrosion resistance in harsh weather.
-
Standard NMO Interface: Compatible with all standard NMO mobile mounts, allowing for versatile installation on trucks, vans, and emergency vehicles.
-
Tunable Whip Design: The 49-inch stainless steel whip can be field-trimmed using the provided cutting chart for optimized VSWR at specific frequencies.
Specifications
-
Brand: TE Connectivity (formerly Laird)
-
Model Number: B1443S
-
Frequency Range: VHF (144-174 MHz)
-
Gain: 3 dBi
-
Base Style: NMO Mount
-
Whip Length: 49 Inches
-
Whip Material: 17-7PH Stainless Steel
-
Power Rating: 200 Watts
-
Ground Plane: Required (Metallic surface)
Compatibility
|
|
|
|
| F5011 |
F5021 |
F6121D |
F5130D |
| F5200D |
F5330D |
F9511S |
|
Frequently Asked Questions
-
Is this antenna a direct swap for the Icom Antenna 2? Yes, the TE Connectivity B1443S provides the same mounting footprint and VHF performance as the discontinued Icom Antenna 2.
-
Does this require a magnetic mount? It requires an NMO mount. This can be a magnetic mount, a trunk-lip mount, or a permanent through-hole mount depending on your vehicle's requirements.
-
Can I use this without a metal roof? No, the TE Connectivity B1443S requires a metallic ground plane (typically the vehicle's roof or trunk) to achieve the specified 3 dBi gain and proper VSWR.
Warranty
5-year manufacturer's warranty.
